Acura & Honda Rods

Call for price

Acura & Honda Rods

Part . .	Engine . .	Cyl . .	C-C . in	C-C . mm	BE DIA in	BE DIA mm	BE W in	BE W mm	SE DIA in	SE DIA mm	SE W in	SE W mm	WT OA g	WT BE g
D17-190-480-1370F	D17	4	5.3940	137.01	1.8903	48.01	0.7800	19.81	0.7485	19.01	0.8500	21.59	484	337
HON-170-430-1290F	EB3	4	5.0780	128.98	1.6933	43.01	0.8580	21.79	0.6690	16.99	0.8500	21.59	437	314
HON-180-430-1490F	L15A	4	5.8660	149.00	1.6934	43.01	0.9020	22.91	0.7080	17.98	0.7020	17.83	449	307
HON-190-430-1380F	D14	4	5.4330	138.00	1.6933	43.01	0.8950	22.73	0.7480	19.00	0.7150	18.16	453	324
HON-190-450-1341F	D15	4	5.2800	134.11	1.7721	45.01	0.8980	22.81	0.7480	19.00	0.8900	22.61	495	363
HON-190-480-1370F	D16	4	5.3940	137.01	1.8903	48.01	0.8920	22.66	0.7480	19.00	0.8000	20.32	503	355
HON-200-480-1370F	A20A	4	5.3940	137.01	1.8902	48.01	0.9350	23.75	0.7874	20.00	0.9350	23.75
HON-200-480-1526F	R20A	4	6.0090	152.63	1.8902	48.01	0.7600	19.30	0.7880	20.02	0.7600	19.30	554	380
HON-200-480-1575F	R18A	4	6.2010	157.51	1.8901	48.01	0.7600	19.30	0.7880	20.02	0.7600	19.30	508	359
HON-210-480-1325F	B17A1	4	5.2080	132.28	1.8902	48.01	0.9350	23.75	0.8273	21.01	0.8500	21.59	553	397
HON-210-480-1344F	B16 VT	4	5.2900	134.37	1.8903	48.01	0.9350	23.75	0.8270	21.01	0.8500	21.59	518	383
HON-210-480-1370F	B18A B18B	4	5.3940	137.01	1.8901	48.01	0.9350	23.75	0.8270	21.01	0.8500	21.59	554	398
HON-210-480-1380F	B18C	4	5.4300	137.92	1.8901	48.01	0.8580	21.79	0.8270	21.01	0.8500	21.59	547	386
HON-210-480-1423F	B16B	4	5.6020	142.29	1.8901	48.01	0.8560	21.74	0.8270	21.01	0.7100	18.03
HON-220-480-1380F	G25A1	5	5.4330	138.00	1.8901	48.01	0.9350	23.75	0.8660	22.00	0.9350	23.75
HON-220-480-1390F	K20Z	4	5.4700	138.94	1.8903	48.01	0.7780	19.76	0.8660	22.00	0.9000	22.86	532	373
HON-220-480-1408F	F22A	4	5.5720	141.53	2.0080	51.00	0.7780	19.76	0.8660	22.00	0.9000	22.86	530	380
HON-220-480-1410F	F23	4	5.5510	141.00	1.8903	48.01	0.7780	19.76	0.8660	22.00	0.7780	19.76	531	379
HON-220-480-1450F	F20A	4	5.7090	145.01	1.8903	48.01	0.9350	23.75	0.8660	22.00	0.9350	23.75
HON-220-510-1389F	K20	4	5.4700	138.94	2.0080	51.00	0.7780	19.76	0.8660	22.00	0.9000	22.86	550	372
HON-220-510-1415F	H23	4	5.5710	141.50	2.0083	51.01	0.9350	23.75	0.8667	22.01	0.9350	23.75	583	399
HON-220-510-1432F	H22 VT	4	5.6360	143.15	2.0083	51.01	0.9350	23.75	0.8667	22.01	0.9350	23.75	596	409
HON-220-510-1520F	K24	4	5.9840	151.99	2.0083	51.01	0.7810	19.84	0.8660	22.00	0.9000	22.86	590	395
HON-220-530-1518F	C30A	6	5.9760	151.79	2.0869	53.01	0.8540	21.69	0.8667	22.01	0.9400	23.88	629	429
HON-220-560-1620F	J30A	6	6.3780	162.00	2.2044	55.99	0.7400	18.80	0.8660	22.00	0.7500	19.05	595	415
HON-220-570-1610F	C32A1	6	6.3380	160.99	2.2438	56.99	0.8560	21.74	0.8665	22.01	0.8560	21.74	617	433
HON-220-570-1645F	C35	6	6.4750	164.47	2.2438	56.99	0.8560	21.74	0.8660	22.00	0.8560	21.74	655	438
HON-220-580-1585F	J35	6	6.2400	158.50	2.2839	58.01	0.7400	18.80	0.8666	22.01	1.0000	25.40	650	437
HON-220-580-1620F	J32A	6	6.3760	161.95	2.2839	58.01	0.7400	18.80	0.8666	22.01	1.0000	25.40	671	450
HON-220-600-1570F	J37A1	6	6.1820	157.02	2.3629	60.02	0.7410	18.82	0.8660	22.00	1.0000	25.40	672	450
HON-230-510-1499F	F22C	4	5.9020	149.91	2.0083	51.01	0.9350	23.75	0.9060	23.01	0.9350	23.75	590	408
HON-230-510-1530F	F20C	4	6.0230	152.98	2.0083	51.01	0.9350	23.75	0.9060	23.01	0.9350	23.75	604	410
HON-230-550-1520F	C32B	6	5.9840	151.99	2.1659	55.01	0.8540	21.69	0.9062	23.02	0.8750	22.23	620	434

Rod Inquiry FormThe connecting rods seen above are inventory items, consisting of stock dimensions and standard features. To inquire about a set of standard sized rods, click here.

About Pauter RodsTo learn more about Pauter rods, head over to the landing page. There you’ll find design and strength information, available variations, and interactive 3D connecting rod models.

Custom Spec Rod FormIf you would like to submit a custom specification build sheet, fill out one of the forms below and email/fax it to: info@pauter.com or (619) 422-1924.
