Suzuki Rods - Pauter

Call for price

Suzuki Rods

Part . .	Description . .	Cyl . .	C-C . in	C-C . mm	BE Dia. in	BE Dia. mm	BE W in	BE W mm	SE Dia. in	SE Dia. mm	SE W in	SE W mm	W OA g	W BE g
SUZ-170-450-1200F	1.0L	3	4.7200	119.89	1.7721	45.01	0.8670	22.02	0.6690	16.99	0.8660	22.00
SUZ-190-450-1200F3	SUZUKI/SPRINT 1.0L	3	4.7200	119.89	1.7721	45.01	0.8600	21.84	0.7480	19.00	0.8650	21.97	465	339
SUZ-190-450-1200F4	SWIFT G13B 1300CC	4	4.7200	119.89	1.7720	45.01	0.8610	21.87	0.7480	19.00	0.8610	21.87	469	341
SUZ-190-470-1395F	1.6L	4	5.4950	139.57	1.8509	47.01	0.8610	21.87	0.7480	19.00	0.8610	21.87	510	360
SUZ-190-470-1430F	G15A	4	5.6300	143.00	1.8508	47.01	0.8640	21.95	0.7480	19.00	0.8640	21.95	469	336
SUZ-200-450-1360F	1.8L	4	5.3540	136.00	1.7721	45.01	0.9350	23.75	0.7870	19.99	0.7400	18.80	530	392
SUZ-200-450-1380F	SWIFT M15A VVT	4	5.4330	138.00	1.7721	45.01	0.9380	23.83	0.7880	20.02	0.7430	18.87	532	394
SUZ-210-530-1430F4	2.0DOHC J20A KIZASHI 16V	4	5.6300	143.00	2.0869	53.01	0.8200	20.83	0.8270	21.01	0.8200	20.83	620	424
SUZ-210-530-1430F6	J20A & 2.3L AERIO	6	5.6300	143.00	2.0869	53.01	0.8200	20.83	0.8270	21.01	0.9000	22.86	620	424
SUZ-210-530-1475F	J18 1.8	4	5.8080	147.52	2.0869	53.01	0.8200	20.83	0.8270	21.01	0.7400	18.80	534	375

Rod Inquiry FormThe connecting rods seen above are inventory items, consisting of stock dimensions and standard features. To inquire about a set of standard sized rods, click here.

About Pauter RodsTo learn more about Pauter rods, head over to the landing page. There you’ll find design and strength information, available variations, and interactive 3D connecting rod models.

Custom Spec Rod FormIf you would like to submit a custom specification build sheet, fill out one of the forms below and email/fax it to: info@pauter.com or (619) 422-1924.
